Spiral Wound Gasket Sterling Seal 9000IR1500316GR600X6 1.5in 600#

Description

Product Overview

The Sterling Seal & Supply SSS 9000IR1500316GR600X6 Spiral Wound Gasket is a premium sealing solution designed for high‑pressure hydraulic and pneumatic systems. Constructed with a 316 stainless steel inner ring, the gasket offers exceptional corrosion resistance and structural integrity, while the flexible graphite filler provides superior compressibility and temperature tolerance. Certified to ASME B16.20 for use with ASME B16.5 flanges, this gasket is rated for Class 600 applications, making it suitable for demanding industrial environments where reliability and safety are paramount.

Key specifications include a 1.5‑inch pipe size, a 600# pressure rating, and an operating temperature range of –150°F to 850°F. The spiral winding design combines metal strips and graphite filler in a tightly wound configuration, delivering consistent sealing performance even under cyclic loading and thermal expansion. The gasket dimensions are compact, with package dimensions of 15 x 11 x 0.5 inches and a lightweight of 4.8 ounces per pack of six, facilitating easy handling and storage.

Usage

This gasket is ideal for a wide range of applications, including oil and gas pipelines, chemical processing plants, power generation facilities, and heavy‑duty manufacturing equipment. Its robust construction allows it to perform reliably in high‑temperature steam lines, corrosive fluid transport, and high‑velocity gas streams. Engineers and maintenance technicians appreciate the gasket’s ease of installation; the centering ring accurately positions the gasket on the flange face, providing additional radial strength and acting as a compression limiter to prevent over‑tightening.

Typical use cases involve sealing connections between carbon steel or stainless steel flanges in systems that operate under extreme pressure and temperature conditions. The gasket’s flexible graphite core adapts to surface irregularities, ensuring a leak‑free seal even when flange surfaces are slightly out of tolerance. This makes it a preferred choice for retrofits, new installations, and critical safety‑related components where downtime must be minimized.

Why Choose Us

Choosing the Sterling Seal & Supply Spiral Wound Gasket means selecting a product backed by decades of engineering expertise and rigorous quality control. Each gasket undergoes comprehensive testing to verify compliance with ASME standards, guaranteeing that it meets or exceeds industry performance criteria. Our manufacturing process utilizes precision winding equipment and high‑grade materials, ensuring uniformity across every unit.

In addition to product excellence, we provide dedicated technical support and after‑sales service. Our engineering team is available to assist with selection, installation guidance, and troubleshooting, helping customers achieve optimal system performance and longevity. With a proven track record of reliability, our gaskets are trusted by leading manufacturers and plant operators worldwide.

Key Features

• High‑temperature resistance from –150°F to 850°F for versatile industrial use
• 316 stainless steel inner ring delivers superior corrosion resistance and strength
• Flexible graphite filler provides excellent compressibility and leak‑proof sealing
• ASME B16.20 certification ensures compatibility with Class 600 flanges
• Dedicated technical support and warranty for peace of mind

FAQ

What flange sizes are compatible with this gasket?

The gasket is designed for 1.5‑inch pipe connections and fits ASME B16.5 flanges rated up to Class 600. It works with both carbon steel and stainless steel flange faces.

Can this gasket be reused after removal?

Yes, the gasket can be inspected and reinstalled if it shows no signs of damage or excessive wear. However, for critical applications, replacement is recommended to maintain optimal sealing performance.

How does the flexible graphite filler improve sealing?

Flexible graphite conforms to surface irregularities and maintains its shape under pressure, providing a consistent seal even when flange surfaces are slightly out of tolerance.

What is the recommended torque for installing this gasket?

Follow the flange manufacturer’s torque specifications. The centering ring on the gasket helps limit compression, preventing over‑tightening and ensuring even load distribution.

Is there a warranty on this product?

All Sterling Seal & Supply gaskets come with a limited warranty covering material defects and manufacturing errors, backed by our responsive customer service team.
